Toptrans 60Km 10G SFP Module 10G SFP+ BIDI TX 1330nm RX 1270nm

Product Categories
TOPSTAR TECHNOLOGY INDUSTRIAL CO., LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Toptrans 60Km 10G SFP Module 10G SFP+ BIDI TX 1330nm RX 1270nm

  • 1
  • 2

Brand Name : Toptrans

Model Number : TOP-BIDI-XFP-ER+-60A

Certification : Rohs

Place of Origin : China

MOQ : 1

Price : negotiable

Payment Terms : L/C, T/T, Western Union, MoneyGram,Paypal

Supply Ability : 20000pcs per month

Delivery Time : 3-4days

Packaging Details : Anti-static package, standard packing

Power Dissipation : <1.8W Maximum

Data Transfer Rate : 10G

Distance : 60Km

DDM : Yes

Wavelength : 1270nm/1330nm

Supply Power : 3.3V

Temperature : 0ºC to 70ºC

Extinction Ratio : 3.5 dB

Contact Now



10G XFPT1270nm R1330nm 60km Optical Transceiver Power Consumption Modules







PRODUCT FEATURES



● Hot pluggable



● Support 9.95Gb/sto11.1Gb/s bit rates



● Below<1.8w power consumption



● XFPMSA package with LC connector



● Digital Diagnostic Monitor Interface



● Very low EMI and excellent ESD protection



● Un-cooled 1270nmDFB laser and APD receiver



● +3.3V single power supply



● operating temperature range 0°Cto70°C



● No reference clock requirement







Optical Module TOP-BIDI-XFP-ER+-60A Specification



Rate 10Gb/s
Wavelength 1270nm/1310 nm
Temperature 0 to 70°C
Distance 60Km
Form Factor XFP
Application 10GBASE-BX10.3125Gb/s Ethernet
Extinction Ratio 3.5dB
Certificate ROHS



APPLICATIONS



●10GBASE-BX10.3125Gb/s Ethernet



●10GBASE-BX9.953Gb/s Ethernet



●SONETOC-192 &SDH STM I-64.1





STANDARD



● XFPMSA Compliant



● SFF-8472reversion9.5compliant



● IEEE802.3-2005compliant



● TelcordiaGR-468-COREcompliant



● FCC47CFRPart15,Class B compliant



● FDA21CFR1040.10and1040.11,class1com-pliant



● RoHS compliant











PRODUCT DESCRIPTIONS



● XFP 10G 60KM 1270transceivers are designed for 10GEthernet



10GBASE-ZR/ZWper802.3ae and10G SOIOC-192/SDHSTM-64,and it can support



data-rate from9.953Gb/sto11.1Gb/s. Digital diagnostics are avail-able viaI2C interface as specified in the XFPMSA.



● The transceiver designs are optimized for high per-formance and cost effective to supply customers the best solutions for



data-comand telecom applications.











Toptrans 60Km 10G SFP Module 10G SFP+ BIDI TX 1330nm RX 1270nm





Toptrans 60Km 10G SFP Module 10G SFP+ BIDI TX 1330nm RX 1270nm






























































































































































































































































Product Tags:

Toptrans 60Km 10G SFP Module



10G SFP+ BIDI TX 1330nm



RX 1270nm 10G SFP Module


Buy cheap Toptrans 60Km 10G SFP Module 10G SFP+ BIDI TX 1330nm RX 1270nm product

Toptrans 60Km 10G SFP Module 10G SFP+ BIDI TX 1330nm RX 1270nm Images
